Entel DT844FF industrial grade DTEx Fire Fighter MED radio
The industrial grade DTEx Fire Fighter Series is designed and approved to meet the latest MED standard implementation regulation MED/5.20 and European ATEX directive.
The ultra durable fire-red coloured DTEx Series sets the benchmark for next-generation MED compliant Firefighter radios. Standard features include high visibility OLED display, high torque ergonomic controls designed for gloved-hand use, and industry-leading IP68 2m 4 hours submersible rating, to provide 100% reliability and usability even in the most extreme conditions.
Entel DT844FF Fire Fighter radio General Features:
Channels
The DT844FF VHF Marine can operate in either USA/INT/CAN modes or a simple custom channel line-up, for example; 6,16,15,17,69,72
Environmental protection to IP68 (2 Meters for 4 hours)
The DT844FF offers the highest submersibility rating of any manufacturer. This protects against corrosion, withstanding total immersion in water to a depth of 2 meters for 4 hours to protect against the likely hazards encountered in extremely wet environments.
Robust accessory socket
DT844FF accessory socket has been specifically designed so that when an accessory is secured to the portable, the connection can withstand any amount of punishment; from dropping to careless misuse. The rugged, multi-pin interface and Micro-USB socket are both submersible and gold-plated to minimize any risk of damage and protect against corrosion. To ensure the integrity of IS protection levels any accessory connected to the handset automatically undergoes a validation process to safeguard against non-compliant accessories being used. All DT844FF accessories incorporate a robust locking connector to further safeguard the safety of the user.
High contrast white on black OLED display
the DT844FF model benefits from a high contrast white on black OLED display that delivers superior readability in varying light conditions adding to the DT844FF’s intuitive user interface.
Li-Ion battery technology & improved talk time
DT844FF radios are supplied with the latest intelligent Lithium-Ion battery technology as standard. One key advantage of Lithium-Ion battery technology is the way it eliminates ‘memory effect’, meaning that there is no need to fully discharge your battery before recharging. As a result of this, you are assured of a full charge each and every time you take your Entel battery from its charger.
Superior Audio
DT844FF portables deliver loud & crisp audio no matter what environment you are in. All of the DT844FF’s range of accessories incorporate a robust locking plug and high-grade cable and benefit from Entel’s proprietary “Smart Speech Tailoring” technology. This automatically detects the type of accessory connected and optimizes the audio accordingly to deliver the very best performance.
Entel DT844FF Fire Fighter radio Convenience Features:
Simple on-board reprogramming app
With our free, unique and simple to use PC app, you can easily re-program a DT844FF radios whilst still onboard. The user friendly app makes it easy to drag and drop a new programming file from an email to your DT844FF radio(s). This is a simple and seamless process that can be carried out by non-technical personnel.
Keylock
To avoid accidental operation, your radio's keys & controls can be locked.
Audio Accessories & BA Support
Entel also offer an extensive range of accessories including Draegor BA, most popular for Fire Fighters is the CXR bone conductive throat and skull microphones which eliminate ambient noise, further enhanced by DT844FF’s speech tailoring technology delivering intelligible communications first time, every time
Entel DT844FF Fire Fighter radio Safety Features:
Entel DT844FF Fire Fighter radio General Specifications:
| Frequency Range | VHF 156 - 163.275MHz |
| Channels | Marine INT/USA & Canadian |
| Battery | CNB950EV2 1800mAh Lithium-Ion |
| Overall Dimensions (HxWxD) | 138mm x 60mm x 38mm |
| Frequency Stability | ± 0.5ppm |
| Operating Voltage | 7.4v |
| Programmable Buttons | 5 |
| Channel Spacing | 25KHz |
| Battery Endurance (5/5/90 - Analog Mode) | 12 hours |
| Battery Endurance (5/5/90 - DMR Mode) | n/a |
Entel DT844FF Fire Fighter radio Transmitter Specifications:
| Output Power | 3.9 Watts |
| Modulation Limiting | ±2.5kHz @ 12.5kHz ±5.0kHz @ 25kHz |
| Conducted / Radiated Spurious Emissions | Better than -36dBm |
| Adjacent Channel Power | Better than 60dB |
| Audio Distortion (typical) | 3% |
Entel DT844FF Fire Fighter radio Receiver Specifications:
| Sensitivity (typical) | -121dBm (0.2uV) for 12dB SINAD |
| Intermodulation response rejection (ETSI) | > 70dB |
| Adjacent Channel Selectivity (ETSI) | > 70dB(12.5KHz) 60dB(25KHz) |
| Spurious Response Rejection (ETSI) | > 70dB |
| Audio Output Power | 1 Watts |
| Audio Distortion (typical) | 3% |
| Conducted Spurious Emission (ETSI) | > - 57dBm |
Entel DT844FF Fire Fighter radio Environmental Specifications:
| Ex Protection | ATEX II 2G Ex ib IIB T4 Gb |
| Operating Temperature | -20°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Thermal Shock, Humidity, Shock & Vibration, Packing Test, Drop Test | MIL-STD-810 C/D/E/F/G |
| Dust & Liquid Ingress | IP68 (2m 4h Submersible) |
