Entel HT944 VHF ATEX IIC Marine Entry LCD Radio
The first time you handle Entel’s HT944 Series 2.0 portable you will be impressed by its superior build quality. The HT944 has been designed specifically for those requiring a no compromise marine portable.
The HT944 portable is ATEX (II 2 G Ex ib IIC T4) Intrinsically Safe certified and approved to the essential IEC 60945 marine environmental standard and fully Submersible to IP68 (2 meters depth for 4 hours).
Entel’s HT944 Series 2 portable will exceed the expectations of even the most experienced radio user.
VHF ATEX IIC Marine Entry LCD Radio
From the rugged ergonomic design that fits comfortably in your hand, to the exceptionally loud audio, the HT944 Series 2 portable easily outclasses the competition.
Entel HT944 VHF ATEX IIC Marine Radio General Features:
MILSTD 810C/D/E/F
Meeting MIL-STD 810C/D/E/F and providing commercial grade construction for tough, enduring performance. Entel's Entel HT944 portable conforms to stringent standards, enabling it to withstand the everyday rigours of shock, vibration and the corrosive effects of dust and moisture, ensuring many years of trouble free use.
Environmental protection to IP68 (2 Meters for 4 hours)
The practical Entel HT944 portable enjoys an IP68 (2 Meters for 4 hours) rated construction, which means that they are dust protected and fully Submersible.
Intrinsically Safe
The Entel HT944 portable is ATEX (II 2 G Ex ib IIC T4) Intrinsically Safe certified.
Robust accessory socket
The socket has been specifically designed so that when an accessory is secured to the portable, the connection can withstand any amount of punishment; from dropping to careless misuse. Furthermore, the securing bolt incorporates a shearing point to protect the connector.
Flash upgradeable to add future features
Entel adds and improves features on its Entel HT944 radio by way of software updates. Using Flash Upgrade technology your Entel HT944 radios can be upgraded by your Dealer at any time.
Channels
The Entel HT944 portable provides all INT, USA & CAN Marine channels.
Entel HT944 VHF ATEX IIC Marine Radio Convenience Features:
Keylock
To avoid accidental operation your radios keys & controls can be locked by the user or, if set, automatically by the radio.
Scan
The Entel HT944 Series portable has the facility to scan for an active channel. When the channel is found, the radio will automatically select the channel for you.
Entel HT944 VHF ATEX Includes:
- CNB950E - 7.4v, 1800mAh rechargeable Lithium-Ion battery pack
- Drop-in charger
- CBH950 - Spring loaded belt clip
- High efficiency antenna (can be exchanged for stubby antenna at point of order)
- User manual
Entel HT944 VHF ATEX IIC Marine Radio General Specifications:
| Frequency Range | 156 - 163.275MHz |
| Channels | All INT, USA & CAN Marine Channels |
| Channel Spacing | 25 kHz |
| Communication Method | Simplex / semi duplex |
| Antenna Impedance | 50 ohm |
| Antenna | Whip / stubby |
| Battery Type | 1800 mAh Li-Ion battery pack |
| Power Supply Voltage | 7.4V DC |
| Current Drain (nominal) | 40mA |
| Duty Cycle (5/5/90) | 14.5 hours |
| Microphone | Internal condenser microphone |
| Operating Temperature | -20° to +55°C |
| Construction | MIL-STD 810C/D/E/F |
| IP Rating | IP68 (2 meters depth for 4 hours) |
| Size (mm) | 59.5(W) x 130(H) x 37(D) |
| Weight | 277g with battery and aerial |
Entel HT944 VHF ATEX IIC Marine Radio Transmitter Specifications:
| Power Output | 1W |
| Modulation | 8K0G3E/16K0G3E |
| Oscillator Method | PLL |
| Frequency Stability | 2.5PPM |
| Maximum Deviation | ±5 kHz |
| Audio Distortion | < 5% (1 kHz 60%) |
| Spurious Emission | -68 [dBc] |
| Hum & Noise | -40 [dB] |
Entel HT944 VHF ATEX IIC Marine Radio Receiver Specifications:
| Receiver Type | Double Super Heterodyne type |
| Sensitivity | -0.25uV (12dB SINAD) |
| Frequency Stability | 2.5PPM |
| Spurious Rejection | -60 dB |
| Adjacent Channel Selectivity | -60 dB (Narrow) , -70 dB (Wide) |
| Distortion | < 5% (1 kHz 60%) |
| Hum & Noise | -40 dB |
| Audio Output | 1W |
