SAILOR 60 GX System
The only choice for easy to deploy, high performance and reliable maritime broadband on Inmarsat Fleet Xpress
The award winning SAILOR 60 GX is the smallest, lightest and most advanced antenna for the new Inmarsat Fleet Xpress High Throughput Satellite (HTS) maritime broadband service. Based on a unique, cutting-edge composite/aluminium design to keep weight down and sophisticated SAILOR VSAT technology for unmatched performance and features, SAILOR 60 GX streamlines the deployment process and maximises operational uptime.
Super light, super rugged
SAILOR 60 GX is built to withstand the toughest sea conditions and still deliver high bandwidth connectivity on Fleet Xpress. It is the fastest tracking antenna available in the 60cm class, with superior dynamic performance in all axes; roll, pitch and yaw. This high performance means that even smaller vessels more affected by rough seas can make the most of maritime broadband on Fleet Xpress, as SAILOR 60 GX can maintain a strong link even in extreme conditions and on the edges of the beams.
Enter the HTS era
Together, SAILOR 60 GX on Fleet Xpress with integrated SAILOR FleetBroadband, provide a step-change in vessel and fleet operation by enabling access to a new wave of IT applications that support operational efficiency and reliability in addition to crew welfare. Fleet Xpress delivers high bandwidth connectivity, while SAILOR 60 GX ensures that it is always available on board so vessels can operate smarter through harnessing the power of connected maritime IT and technology.
A simple revolution in VSAT deployment
SAILOR 60 GX is delivered ready to install, with the included SAILOR GX Modem Unit (GMU) and SAILOR Antenna Control Unit (ACU) ensuring quality and reliability throughout the system. Installation is easy, thanks to a wealth of features and design details unique to the SAILOR VSAT technology platform. For instance, it uses a single cable between antenna and below deck equipment for RF, power and data, while Automatic Azimuth Calibration and Automatic Cable Calibration enable unique 'one touch commissioning'. It also features Dynamic Motor Brakes inside the antenna, removing the requirement for mechanical brake straps whilst ensuring the antenna is kept in balance in no-power situations, at sea or during transport.
Streamlining remote access and diagnostics
Just like all SAILOR VSAT systems, the SAILOR 60 GX is incredibly easy to manage; ensuring the best possible support is available anywhere in the world. Easy remote access and diagnostic features include monthly statistics logging, SNMP and built-in e-mail clients that automatically email historical logging of system performance.
SAILOR 60 GX Includes:
407006A Above Deck Unit (ADU), incl. 65cm reflector, 5W BUC, LNB, Mounting Accessories.
407016C Antenna Control Unit (ACU), AC Powered for 19" rack mounting (1U).
AC Power cord.
NMEA Multi-plug.
2x 1m 75 Ohm coax cable TX/RX ACU-VMU.
Ethernet cable.
407023A GX Modem Unit (GMU) for 19" rack/cabinet mounting (1U).
2x RS-232/RS-422 serial cable.
1x 115/230VAC Power cord.
ILOR 60 GX System Key Features:
- Remote or local simultaneous software update of GMU, ADU and ACU via PC and Internet browser.
- Global RF configuration.
- Full remote control and troubleshooting with built-in test equipment (BITE).
- ACU with 4 x LAN, NMEA 0183, NMEA 2000, RS-232 and RS-422.
- ACU is DC powered. Start up voltage: 22 VDC guaranteed, operating range : 20 – 32 VDC
- GMU with 8+2 LAN, RS-232 and RS-422 and I/O connector.
- Single 50 Ohm coax cable for the ADU.
- One-Touch Commissioning.
- Gyro-free operation.
- SNMP support.
- Secure connection, HTTPS and SSH.
- Remote access using SAILOR FleetBroadband over WAN.
SAILOR 60 GX System System Specifications:
| Frequency band | Ka-Band (Inmarsat GX) |
| Reflector size | 65 cm / 25.5 inch |
| Type Approvals | Inmarsat |
| Certification | Compliant with CE (Maritime), ETSI, FCC |
| System power supply range | 100 – 240 VAC, 50-60 Hz |
| Vibration operational | EN60945, DNV 2.4-A, MIL-STD-167-1 |
| Vibration, survival | EN60945, MIL-STD-167-1 |
| EN60721-3-6 6M3 mod | by EN60721-4-6 |
| Shock | EN60721-3-6 class 6M3 mod. by EN60721-4-6 |
| Temperature (ambient) Operational | -25°C to 55°C |
| Storage | -40°C to 85°C |
SAILOR 60 GX System Frequency band:
| Rx | 19.2 to 20.2 GHz |
| Tx | 29.0 to 30.0 GHz |
| Cable - ACU to ADU cable | Single 50 Ω coax for Rx, Tx and power |
| Connectors - ADU | Female N-Connector (50 Ω) |
| Connectors - ACU | Female N-Connector (50 Ω) |
| Connectors - ACU to ADU cable requirements | RF loss at 1950 MHz < 20dB, 4450 MHz < 35 dB. |
| Connectors - DC resistance | < 0.9 Ω |
SAILOR 60 GX System Above deck unit (ADU):
| Antenna type | pedestal 3-axis stabilised tracking antenna with integrated GNSS (GPS, GLONASS, Beidou) |
| Antenna type | reflector system Reflector/sub-reflector, ring focus |
| Transmit Gain | 43.4 dBi typ. @ 29.5 GHz (excl. radome) |
| Receive Gain 40.4 dBi typ. @ 19.7 GHz (excl. radome) | |
| System G/T | 17.2 dB/K typ. @ 19.7 GHz, at ≥10° elevation and clear sky (incl. radome) |
| BUC output power | 5 W Inmarsat GX BUC |
| EIRP | 50.4 dBW typ. @ 29.5 GHz |
| LNB | Inmarsat GX approved LNB |
| Tracking Receiver | Internal “all band/modulation type” including e.g. power, DVB-S2, GSC and modem RSSI |
| Polarisation | Circular Cross-Pol (Inmarsat GX, TX - RHCP, RX - LHCP) |
| Tracking | 6-axis MEMS INU, conical scan, internal GNSS and |
| Gyro/GPS | Compass input |
| Elevation Range | -28° to +120° |
| Cross Elevation | +/-42° |
| Azimuth Range | Unlimited (Rotary Joint) |
| Ship motion | combined angular min. Roll +/-25° (in 6 sec), Pitch +/-15° (in 5 sec), Yaw +/-10° (in 8 sec) |
| Ship, turning rate and acceleration | 15°/S and 15°/S2 |
| ADU motion | linear Linear accelerations +/-2.5 g max any direction |
| Satellite acquisition | Automatic – with or without Gyro/GPS Compass input |
| Humidity | 100%, condensing |
| Rain / IP class | EN60945 Exposed / IPX6 |
| Wind | 80 kt. operational 110 kt. survival |
| Ice survival | 25 mm / 1 inch |
| Solar radiation | 1120 W/m2 to MIL-STD-810F 505.4 |
| Compass safe distance | 1 m / 40” to EN60945 |
| Maintenance, scheduled | None |
| Maintenance, unscheduled | All electronic, electromechanical modules and belts are replaceable |
| Built In Test | Power On Self Test, Person Activated Self Test and Continuous Monitoring w. error log |
| Power | OFF Automatic safe mode |
| Dimensions (over all) Height | H 91 cm / 36 inch |
| Diameter | Ø 82 cm / 32 inch |
| Weight | 37 Kgs. / 82 lbs. |
